Commercial Awning Window

Commercial Series | Series 456

Residential awning sashes inlaid directly into shopfront framing.

Features & Benefits

  • This commercial awning window has a dedicated head and sill to accept awning sashes with manual chain winders with Standard 30mm or alternative 44mm nailing fin jambs. We also have a double glazed 44mm nailing fin frame for those projects with double glazed fixed lights.
  • This awning window complies with AS 2047, with a high water resistance of 450Pa. Has a very low air infiltration that makes this product suitable for air conditioned buildings.
  • Besides the standard manual chain winders, the awning sashes can be fitted with concealed electric chain winders or cam handles.
  • Awning window flyscreens can be fitted behind awning sashes with winders.
  • Wrap around light sashes will accept glass up to 6.76mm thick. We also have wrap around sashes that will accept 20mm IGUs. The heavy duty beaded sash will accept glass from 4mm to 20mm thick.
Download Product Brochure View Wers Info

Product specifications

  • Maximum Panel Height* :Various
  • Maximum Panel Width* :Various
  • Maximum Glass Thickness :≤ 20mm
  • SHGC Range :0.27 - 0.61

Testing & Certification

  • Acoustics Tested & Certified
  • AS2047 Performance Tested
  • BAL40 Bushfire Tested & Certified
