Commercial Aluminium Door (Double Side Beaded)

Commercial Series | Series 52

Series 52 doors are 50mm thick for added strength.

Features & Benefits

  • Can be configured as hinged, sliding or pivot door.
  • Series 52 doors have removable snap-on glazing beads on horizontals and verticals (both sides).
  • Stile to rail joint is securely fixed with custom spigot assembly.
  • Spigots are secured to rails with 10# spline screws.
  • Glass can be blocked and fitted with adjustable setting block.
  • Series 52 doors will accept glass up to 28mm thick.
  • When configured as sliding panels, heavy duty bottom rolling running gear or alternative Centor E3 top-hung rollers deliver smooth reliable operation.
  • Horizontal rails can be fitted with square or splayed glazing beads.
  • 19mm high glazing beads ensure that the glass gets the right bite.
  • Can be security glazed with captive external glazing wedge.
  • Four midrail options 50mm and 115mm deep with single external bead. Plus 125mm and 200mm midrails with four glazing beads.
  • Lock stile wide enough to accept most lock types.
  • Rebated French meeting stiles.
  • Can be fitted with Centor S1E Eco Screen
  • NOTE: BAL-40 rating applies to hinged configuration only.
Download Product Brochure View Wers Info

Product specifications

  • Maximum Panel Height* :3000mm
  • Maximum Panel Width* :various
  • Maximum Glass Thickness :≤ 28mm
  • SHGC Range :0.14 - 0.54

Testing & Certification

  • BAL40 Bushfire Tested & Certified
